The Secret to a Leak Free Windshield on Your ClassicAdmin
If you’re a Steele customer or you’ve seen our advertising you know our main focus is making parts designed from originals so they fit like they came from the factory and, in turn, won’t leak. However, when it comes to your windshield, rear window or any other stationary glass in your vehicle, it takes more than a superior gasket to avoid leaks. There’s an extra step you should take to seal between that gasket and the body of the vehicle- you need to use Automotive Bedding and Glazing Compound.
What is Bedding & Glazing Compound?
Bedding & Glazing Compound is a sealer designed specifically for creating a watertight seal between the windshield rubber gasket and auto body. Here at Steele, we recommend the 3M brand (3M part number 08509).
It is a rubber-based formula that never hardens so it remains flexible. That makes it the perfect solution for sealing glass and acting as a buffer for the window on a vehicle that’s always shifting and vibrating.
- Has non-sagging properties making it great for vertical and overhead applications
- It’s a one-part sealer so there’s no mixing required
- Comes in a caulking tube for easy application.
- Did I mention that it won’t harden or crack EVER?! This stuff is amazing.
Side Note: Urethane Adhesive should NEVER be used in place of Bedding & Glazing Compound. Urethane Adhesive will bond windshield, gasket and body together and you’ll have problems replacing the windshield if you need to later on. Urethane Adhesive might look similar but is a much different product and we only recommend using it in place of butyl tape when gluing in your windshield. For more information about Urethane Adhesive read our article Where has all the Butyl tape gone?
When should you use Bedding & Glazing Compound?
When installing a window – windshield, rear window, rear quarter or any other glass that uses a rubber gasket. You can also use it to repair leaking areas.
Why should you use Bedding & Glazing Compound?
For a truly leak free window you need to seal any and all places that water can get in. Gaskets are made to fit to the glass exactly and when you put them onto the vehicle, they fit into the allotted space well but do not create a watertight seal. Taking the extra step to use Bedding & Glazing Compound will seal everything up and avoid that dreaded wet carpet, water dripping on the dash and ultimately, rust.
Bedding & Glazing Compound was used on the assembly line when these classic cars were new so it’s certainly not a step you should skip in your restoration.
How do you use Bedding & Glazing Compound during a gasket/glass installation?
- 3M brand Automotive Bedding and Glazing Compound
- Rubber gloves
- Steele Rubber Products Gasket of your choice
- Caulk gun
- Auto Body Tape
*Just a warning- this can get messy, but it’s worth it.
Once you’ve removed the old windshield/back window and gasket, clean the body where the gasket will lay. Making sure this area is clean and free of debris will help the Bedding & Glazing Compound do its job.
Because of the above mentioned mess, the next step we’d recommend is taping around the window opening with some Auto body tape. This will make cleanup a breeze- and possibly lower your stress levels too.
For locking strip type gaskets that are installed on the pinch weld first, lay a bead of Bedding & Glazing Compound on the pinch weld all the way around the opening and push the gasket on as usual. If your gasket is installed on the glass first, lay a bead of Bedding & Glazing Compound on the body of the vehicle where the gasket will lay on it. Lay another bead on the underside of the gasket and install the glass as usual. Be sure to use spacers and/or tape to hold everything where it should be until it cures.
If your vehicle allows you can also install the gasket/glass first and then apply the Bedding & Glazing Compound after (always from the outside of the vehicle) or put some additional on after the installation if more is needed.
Tip: Always apply Bedding & Glazing Compound from the outside of the vehicle. It almost never rains inside a vehicle, so you don’t need it in there.
3M Automotive Bedding & Glazing Compound has a 40-50 minute working time so don’t stress! You can take your time and still get the glass placed before anything starts to set up.
Once everything is in place, go back with a dry rag to clean up. You can also use denatured alcohol, if needed.
Bedding & Glazing Compound cures in as little as 24 hours so leave it in a dry, safe place for a day or two and you’re all set.
How do you use Bedding & Glazing Compound for repairing a leak?
Locate the area of the leak.
Apply Bedding & Glazing Compound to the area making sure to squirt it into any gaps or open areas. Again, always apply it from the outside of the vehicle.
Clean up and wait at least 24 hours and test it to see if it leaks again.
